Cat 3 Ton

The right equipment, at the right time, at the right price.

Equipment Information

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity),L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel

Specifications

Nominal load at COG : 3 t
Engine type : S4S
Standard tyres : 2x/2SE
Engine power : 44 kW
COG : 500 mm
Transmission type : W
Net weight : 4.48 t
Total width : 1710 mm
Construction height : 2173 mm
Turning radius : 2.38 m
Lifting height by max. Carrying capacity : 3.27 m
Travel speed with / without load : 19/19,5 km/h
Hoisting with / without load : 0,51/0,54
Lowering with / without load : 0,53/0,5
Max. climbing ability : 24 %

Interested in hiring this?
